UCL Data Centre
/0 Comments/in Completed Data Centre Projects /by phoenixmeProjects
UCL Data Centre
Phoenix were appointed and responsible for the full Design and Build of a new Data Centre for UCL in Torrington Place, London.
This is a purpose built facility being constructed in an existing car park and basement with a separate Energy Centre containing the main switchgear and generators. There is also a vast mechanical plant area with 5no chillers situated in the chiller compound at basement level.
Our works consist of;
ELECTRICAL – Package substations, LV switchgear, Busbar, HV & LV Submains Cabling and termination Generators, UPS, Lightning Protection, Earthing, Small Power, Lighting, Emergency Lighting, VESDA, Fire Alarm, BMS & EMS systems
MECHANICAL – Chillers and associated Plant, CHW Pipework, In Row Cooling Units, Rear Door cooling units, DX Cooling systems, Lagging, Watermist and Hypoxic systems, Trace Heating, Leak Detection
IT SYSTEMS – Racks, Hot aisle containment, Fibre Cabling & terminations, Copper cabling & terminations, Rack Mounted PDU’s
Value: £12.2M Scope: M&E Completion: May 2018
MORE PROJECTS
Fujitsu Data Centre
/0 Comments/in Completed Data Centre Projects /by phoenixmeProjects
Fujitsu Data Centre
Phoenix ME undertook the lead co-ordination and installation of a new independent N+1 1MW Data Hall. Currently positioned within a live data facility.
Data hall 7 consisted of 2 areas, 7A which was fitted out, and 7B which was left as an empty shell. Hall 7A utilises the new cold aisles with a cooling water system from the existing data centre infrastructure, supplying the computer room air cooling (CRAC) units located in the hall; All serviced by means of pre-fabricated mild steel pipework located within the floor.
The data hall had new electrical supplies that was installed on co-ordinated containment from the Fujitsu existing switchrooms and data hall 7. These supplied new Power Distribution Panels, CRAC Distribution Panels & Distribution Boards. The hall has been divided between an A supply and a B Supply. All A&B PDU’s feed the 250A 5Pole busbars that have been installed for the data cabinets. The CDP’s feed the 8no. CRAC units, these have integral ATS switches should there be mains failure. Both distribution boards supply all the lighting and general power
The project has a new lightning protection system that was installed from the roof of the new building to 8 individual earth pits dedicated to the data hall 7 building.
Data Hall 7 had extension to the existing BMS, security, lighting control, fire alarm system, VESDA system, sprinkler system & gas suppression.
Value: £3M Scope: M&E Completion: Jul 2018
MORE PROJECTS
Credit Suisse
/0 Comments/in Data Centre Projects /by phoenixmeProjects
Credit Suisse
PME were appointed to carry out the Cat B Fit-Out and infrastructure upgrade for Credit Suisse at Canary Wharf.
Works consisted of the Electrical, Mechanical and Public health services across 20 floors, into 3 phases.
PME were lead Co-ordinator on the project with all co-ordination drawings completed in 3D following extensive surveys of existing services and building structure.
The MEP Services consist of new containment, LV system, UPS systems serving Traders floors, modular wiring system serving 10,900 new lights including specialist lighting, BMS backbone wiring, energy monitoring system, leak detection, small power, submains and tap offs, PDU’s, 54no AHU refurbishments, 1600 VAV Units, supply & extract ductwork distribution system, miscellaneous fans, FCU’s, CRAC Units, CHW pipework, domestic pipework, drainage pipework, gas pipework and DX pipework. PME carried out full MEP testing & commissioning including , Air Quality and Heat Load Testing.
The new services serve a variety of areas within the buildings which consist of specialist floors, standard floors, Traders Floors, exposed services areas, SER & MER Rooms, Auditorium, Kitchens & Pantry’s, Refreshment hubs, Receptions, Toilets, Showers, Business Gardens, Multi faith rooms, Plantrooms & Risers and Lift Lobbies
Value: £36M Scope: M&E Completion: Dec 19
